Thông tin chi tiết sản phẩm:
|
Mô hình: | 608-2Z | Product Name: | SKF Deep Groove Ball Bearing |
---|---|---|---|
No. of Row: | Single Row | lồng: | Kim loại |
Seal: | ZZ / 2Z | Độ chính xác: | P0 P6 P5 |
Material: | Chrome steel | Ứng dụng: | Máy móc, đồ chơi, dụng cụ thể thao, quạt |
Làm nổi bật: | Đồ đeo quả bóng chất lượng cao,Đường xích xe máy Đường xích quả bóng,Lối đệm xe trượt ván tốc độ cao |
SKF Deep Groove ball bearings are the most popular of all the ball bearing types because they are available in a wide variety of seal, shield and snap-ring arrangements.The bearing ring grooves are circular arcs made slightly larger than the radius of the ball.
Application :
They are widely used in metallurgy, power, petrochemical, construction machinery, railway, steel, papermaking, cement, mining and other industries. They are widely used of vehicles, motorcycles, home electrical appliances, electric tools and mineral machineries.
In accordance with the sizes of deep groove ball bearings can be divided into:
( 1 ) miniature bearings ---- nominal diameter size range of 26mm bearings ;
( 2 ) small bearing ---- nominal diameter size range of 28-55mm bearings ;
( 3 ) small and medium-sized bearings ---- nominal diameter size range of 60-115mm bearings ;
( 4 ) large bearing ---- nominal diameter size range of 120-190mm bearings ;
( 5 ) large bearing ---- nominal diameter size range of 200-430mm bearings ;
( 6 ) large bearing ---- diameter size range of 440mm or more bearings
6000 series | 6200 Series | ||||||
N0. | d - mm | D - mm | W - mm | N0. | d - mm | D - mm | W - mm |
604 | 4 | 12 | 4 | 624 | 4 | 13 | 5 |
605 | 5 | 14 | 5 | 625 | 5 | 16 | 5 |
606 | 6 | 17 | 6 | 626 | 6 | 19 | 6 |
607 | 7 | 19 | 6 | 627 | 7 | 22 | 7 |
608 | 8 | 22 | 7 | 628 | 8 | 24 | 8 |
609 | 9 | 24 | 7 | 629 | 9 | 26 | 8 |
6000 | 10 | 26 | 8 | 6200 | 10 | 30 | 9 |
6001 | 12 | 28 | 8 | 6201 | 12 | 32 | 10 |
... | ... | ... | ... | ... | ... | ... | ... |
6300 Series | 6400 Series | ||||||
N0. | d - mm | D - mm | W - mm | N0. | d - mm | D - mm | W - mm |
6300 | 10 | 35 | 11 | 6401 | 10 | 35 | 11 |
6301 | 12 | 37 | 12 | 6403 | 12 | 37 | 12 |
6302 | 15 | 42 | 13 | 6404 | 20 | 72 | 19 |
... | ... | ... | ... | ... | ... | ... | ... |
6800 Series | 6900 Series | ||||||
N0. | d - mm | D - mm | W - mm | N0. | d - mm | D - mm | W - mm |
685 | 5 | 11 | 3 | 693 | 3 | 8 | 3 |
686 | 6 | 13 | 3.5 | 694 | 4 | 11 | 4 |
687 | 7 | 14 | 3.5 | 695 | 5 | 13 | 4 |
688 | 8 | 16 | 4 | 696 | 6 | 15 | 5 |
689 | 9 | 17 | 4 | 697 | 7 | 17 | 5 |
6800 | 10 | 19 | 5 | 698 | 8 | 19 | 6 |
6802 | 15 | 24 | 5 | 6900 | 10 | 22 | 6 |
... | ... | ... | ... | ... | ... | ... | ... |
Packaging & Shipping :
Packing :
1 ) . Origin packing + Pallets.
2 ) . Single boxes + Outer carbon + Pallets
3 ) . Tube package + Outer carbon + Pallets
4 ) . According to your requirements
Delivery :
1 . ) 1 - 3 days for sample
2 . ) 5 - 30 days for bulk order
Shipping :
1 ) . For a small order , send by UPS , DHL , FEDEX , or EMS
2 ) . For bulk order , send by Air or by Sea
3 ) . Our shipping ports are Shanghai , Qingdao , Guangzhou and Shenzhen
Warehouse stock :
